Disc Feeder
CATHAY disc feeder is a high-precision quantitative feeding equipment designed for mining, cement, metallurgy and other industries. It adopts wear-resistant alloy material and optimized transmission structure to ensure uniform and stable transportation of powdered and granular materials.
Core advantages:
✔ Wear-resistant and durable: manganese steel/alloy lining, life is increased by 2-3 times
✔ Accurate feeding: frequency conversion speed regulation, error ≤±2%
✔ Low maintenance: sealed bearing design, dustproof and anti-stuck
✔ Flexible customization: disc diameter φ800-3000mm optional, support explosion-proof/intelligent upgrade
Product introduction
The main function of the disc feeder is to supply material to other equipment. The disc feeder can make the material enter into one equipment evenly so that the next process can work properly, save labor, protect the performance of the equipment and prolong the service life of the equipment in the whole production line. Disc feeder is an indispensable auxiliary product for mineral processing equipment.
CATHAY disc feeder is a highly efficient quantitative feeding equipment designed for mining, building materials, chemical and other industries. It adopts advanced manufacturing technology and high-quality materials to ensure the accuracy and stability of material transportation.
1. Precise quantitative
- Using variable frequency speed regulation technology, the feeding accuracy can reach ±2%
- Unique disc structure design ensures uniform distribution of materials
- Adjustable baffle height to accurately control the feeding amount
2. Super wear-resistant
- The disc surface adopts 16Mn wear-resistant steel plate or ceramic lining
- Special hardening treatment of key parts
- The service life is more than 50% longer than ordinary products
3. Stable and reliable
- Heavy-duty reducer drive, stable operation
- Fully sealed bearing seat, dustproof and waterproof
- Low failure rate, can work continuously for 24 hours
4. Intelligent control
- Optional intelligent control system
- Support remote monitoring and adjustment
- Can be connected to the factory DCS system
Application areas
✔ Concentrate and tailings transportation in mine dressing plants
✔ Raw material, clinker and coal powder feeding in cement plants
✔ Sintering materials and auxiliary materials distribution in the metallurgical industry
✔ Quantitative supply of powder materials in the chemical industry
Core advantages:
✔ Wear-resistant and durable: manganese steel/alloy lining, life is increased by 2-3 times
✔ Accurate feeding: frequency conversion speed regulation, error ≤±2%
✔ Low maintenance: sealed bearing design, dustproof and anti-stuck
✔ Flexible customization: disc diameter φ800-3000mm optional, support explosion-proof/intelligent upgrade
Product introduction
The main function of the disc feeder is to supply material to other equipment. The disc feeder can make the material enter into one equipment evenly so that the next process can work properly, save labor, protect the performance of the equipment and prolong the service life of the equipment in the whole production line. Disc feeder is an indispensable auxiliary product for mineral processing equipment.
CATHAY disc feeder is a highly efficient quantitative feeding equipment designed for mining, building materials, chemical and other industries. It adopts advanced manufacturing technology and high-quality materials to ensure the accuracy and stability of material transportation.
1. Precise quantitative
- Using variable frequency speed regulation technology, the feeding accuracy can reach ±2%
- Unique disc structure design ensures uniform distribution of materials
- Adjustable baffle height to accurately control the feeding amount
2. Super wear-resistant
- The disc surface adopts 16Mn wear-resistant steel plate or ceramic lining
- Special hardening treatment of key parts
- The service life is more than 50% longer than ordinary products
3. Stable and reliable
- Heavy-duty reducer drive, stable operation
- Fully sealed bearing seat, dustproof and waterproof
- Low failure rate, can work continuously for 24 hours
4. Intelligent control
- Optional intelligent control system
- Support remote monitoring and adjustment
- Can be connected to the factory DCS system
Application areas
✔ Concentrate and tailings transportation in mine dressing plants
✔ Raw material, clinker and coal powder feeding in cement plants
✔ Sintering materials and auxiliary materials distribution in the metallurgical industry
✔ Quantitative supply of powder materials in the chemical industry
Source ID
#105
Images
7
Specs
7
Section 02
Technical Specifications
Verified manufacturer specifications for engineering review.
7 parameters
| Model | Gear ratio | Power (kW) | Weight (kg) | Shape size (mm) | Capacity (m³/h) | Granularity (mm) | Disc revolution (r/min) |
|---|---|---|---|---|---|---|---|
| DK6 | 53 | 1.1 | 403 | 855×960×925 | 0.6-4 | 25 | 8 |
| DK8 | 53 | 1.1 | 555 | 1085×1089×1520 | 2-8 | 30 | 8 |
| DK10 | 52 | 1.5 | 827 | 1350×1350×1427 | 3-20 | 40 | 7.5 |
| DK13 | 54 | 3 | 1150 | 1735×1516×1427 | 5-30 | 50 | 6.5 |
| DK16 | 62 | 4 | 2125 | 2115×2050×1535 | 7-35 | 60 | 6 |
| DK18 | 62 | 5.5 | 2900 | 2365×2030×1963 | 10-60 | 70 | 5 |
| DK20 | 62 | 5.5 | 3140 | 2620×2150×2165 | 15-38 | 80 | 5 |
