CATHAY bucket wheel sand washing machine | Sand and gravel aggregate cleaning rate 99% Support customization

Bucket Sand washer is a washing equipmentforsandstone.It is widely used in sand and stone yard,mine, building material,transportation, chemical industry,water conservancy and hydropower,concrete mixing station and other industries for material washing.It can remove the impurities covering the surface of sand and destroy the water vapor layer covering sand grains,so as to facilitate dewatering and play an efficient sand washing role.It is a washing equipment for sand and slag particles.
product introduction
CATHAY bucket wheel sand washer is specially designed for cleaning of sand and gravel aggregates and mine tailings. It integrates powerful cleaning + fine sand recovery dual systems, with a cleaning rate of ≥99%, a fine sand recovery rate of ≥98%, and a single machine processing capacity of 50-500 tons/hour.
Core advantages
✅ High cleaning rate
- Multi-bucket wheel tumbles vigorously, mud and sand are separated thoroughly
- The mud content of finished sand is ≤0.8% (national standard requires ≤3%)
✅ Zero loss of fine sand
- Cyclone + dewatering screen recovery system
- Fine sand (0.075-0.6mm) recovery rate ≥98%
✅ Save water and electricity
- Water consumption is only 1.5m³/ton of sand (traditional equipment 3-5m³)
- Energy-saving motor saves 30% of electricity
✅ Durable and maintenance-free
- The blade is made of wear-resistant alloy steel (lifetime 20,000 hours)
- Sealed bearing design, maintenance-free for 2 years
Technical parameters
| Parameters | Standard model LX-2000 |
| Processing capacity | 200t/h |
| Bucket diameter | Φ3000mm |
| Power | 22kW (main washing) + 7.5kW (recovery) |
| Water consumption | 300m³/h |
| Cleaning rate | ≥99% |
| Fine sand recovery rate | ≥98% |
Compared with traditional equipment
| Indicators | CATHAY bucket wheel | Traditional spiral sand washer |
| Cleaning rate | 99% | 85%-90% |
| Fine sand loss rate | <2% | 15%-25% |
| Water consumption per ton of sand | 1.5m³ | 3-5m³ |
Applicable scenarios
✔ Sand washing in sand and gravel plants ✔ Sand mining and mud removal in rivers
✔ Construction waste recycled aggregate treatment ✔ Iron ore tailings recovery
Table parameters
轮斗直径(mm) Diameter
转速(r/min) Speed
处理能力(t/h) Capacity
外形尺寸(mm) Shape size
Bucket Sand Washer
